产品特点
配置参数
标准配置 | standard parameters | |
整车参数 overall parameter | 整车尺寸vehicle size (mm) | 7310*2200*2900 |
载客人数 passenger capacity | 40/14-25 | |
轴距 wheel base (mm) | 3380 | |
前后悬 front/rear overhang | 1740/2190 | |
前后轮距 front/rear tread | 1850/1681 | |
接近角离去角 approach/departure(º) | 9/8 | |
最大爬坡度 max. grade-ability(%） | ≥25% | |
最高车速 top speed (km/h) | 69km/h 带限速装置 with speed limit device. | |
整备质量curb weight (kg) | 6000 | |
最大总质量gross weight (kg) | 8700 | |
底盘 chassis | 发动机型号 engine model | yc4fa130-40 发动机后置 rear mounted engine. |
发动机排量 engine displacement | 2.982l | |
发动机最大功率 max.power/rotating speed (kw/rpm) | 95kw 3200r/min | |
发动机最大扭矩 max. torque/rotating speed (kw/rpm) | 340n.m 1600～2400r/min | |
前桥 front axle | 东风 dongfeng | |
后桥 rear axle | 东风 dongfeng | |
变速箱 transmission | 手 动 5 挡 manual 5 speed | |
离合器 clutch | 单片膜片弹簧 single diaphragm spring | |
悬 架 suspension | 钢板弹簧 leaf spring | |
转向 steering | 整体式动力转向 integral power steering | |
制动器 braking | 前盘后鼓，双回路气制动，abs, 自调臂 front disc and rear drum; dual circuit air brake, abs, auto slack adjuster. | |
冷却系统 cooling | 水 冷 water cooling | |
轮胎规格 tyre： | 7.50r20-14pr 钢轮毂 steel rim 无内胎子午线轮胎tubeless radial tire | |
电器 electronic | 空调系统a/c | 单冷空调 18000kcal/h cold air conditioner 18000kcal/h |
除霜系统 defrosting | 水暖除霜 water heat defroster | |
雨刮器 windscreen wiper | 双速，带洗涤器 dual speed with scrubber | |
仪表 instrument | can 总线仪表, 发泡仪表台 bus instrument, coaster dashboard | |
影音audio-system | mp5 | |
蓄电池 battery | 120ah，免维护 maintenance-free | |
车身 body | 骨架 body frame | 骨架采用专用钢材，经除污、除锈、磷化处理；蒙皮采 用镀锌钢板，滚压成型张拉蒙皮；车顶，车侧蒙皮夹层 内采用阻燃发泡材料完全填充 the skeleton is made of special steel, after cleaning, derusting, phosphating treatment; the roof and side skin interlining fully populated with flame retardant foam materials. |
乘客门 passenger door | 前单，中双开气动内摆门。 front and middle inner swing door | |
窗门，玻璃 window； glass | 侧窗玻中玻推拉窗，前档夹胶玻璃，后档钢化玻璃， 司 机推拉窗，方便驾驶员调节后视镜。f绿 side window is sliding window, laminated glass in the front and tempered glass in the rear，driver sliding window, should be convenient to open for driver to adjust rear view | |
驾驶座椅 driver seat | 可调带机械缓冲驾驶员座椅 adjustable mechanical shock absorb driver seat | |
乘客座椅 passenger seat | 24 1公交专用座椅，2 2排列 24 1 plastic city bus seats, 2 2 arrangement | |
内 饰 interior | 发泡吸塑风道，pvc 复合侧板 foam suction duct, pvc composite side plate | |
灯具 lights | 前后组合大灯，雾灯，led日间行车灯 front and rear combination light. fog light, led day light | |
后视系统 rear-view system | 内视镜、手动倒车镜 endoscope, manual reversing mirror 车载监控系统，5个摄像头. 中控显示屏，倒车影像。 on board monitoring system with 5 cameras. central monitoring display. reversing camera. | |
地板革及地板 floor and floor cover | pvc板，防滑阻燃地板革 pvc floor, anti-slippery, flame retardant leather | |
天窗 roof hatch | 安全顶通风窗，1 个 safety top ventilation window, 1pc | |
油漆 paint | 标配实色漆 standard solid paint | |
